EEU-FR1J101L
Manufacturer:
Panasonic
Mfr.Part #:
EEU-FR1J101L
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial,8.00mm×15.00mm Through Hole 100 µF 20 % 63 V
| Parameter | Value |
|---|---|
| Capacitance | 100 µF |
| Voltage Rating (DC) | 63 V |
| Tolerance | 20 % |
| ESR (Equivalent Series Resistance) | 68 mΩ |
| Life (Hours) | 8000 Hours |
| Ripple Current | 741 mA |
| Height - Seated (Max) | 15 mm |
| Length | 15 mm |
| Termination | Radial |
| Diameter | 8 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Height | 15 mm |
| Packaging | Bulk |
| Voltage Rating | 63 V |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Diameter | 600 µm |
| Lead Pitch | 3.5 mm |
| Voltage | 63 V |
| REACH SVHC | No SVHC |
| Impedance | 68 mΩ |
| Ripple Current (AC) | 741 mA |
| Lifecycle Status | Production (Last Updated: 5 months ago) |
| Schedule B | 8532220020 |
| Ripple Current @ Low Frequency | 518.7 mA @ 120 Hz |
| Ripple Current @ High Frequency | 741 mA @ 100 kHz |
Stock: 1133
Distributors
pcbx
pcbxUnit Price$0.45055
Ext.Price$0.45055
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.45055 | $0.45055 |
| 10 | $0.15987 | $1.59870 |
| 50 | $0.14126 | $7.06300 |
| 100 | $0.12482 | $12.48200 |
| 500 | $0.11824 | $59.12000 |
| 1000 | $0.11200 | $112.00000 |
| 3000 | $0.11114 | $333.42000 |
| 5000 | $0.11029 | $551.45000 |
