EEU-FR1J561SB
Manufacturer:
Panasonic
Mfr.Part #:
EEU-FR1J561SB
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial,16.00mm×20.00mm Through Hole 560 µF 20 % 63 V
| Parameter | Value |
|---|---|
| Capacitance | 560 µF |
| Voltage Rating (DC) | 63 V |
| Tolerance | 20 % |
| ESR (Equivalent Series Resistance) | 29 mΩ |
| Life (Hours) | 10000 Hours |
| Ripple Current | 2.153 A |
| Height - Seated (Max) | 20 mm |
| Length | 20 mm |
| Termination | Radial |
| Diameter | 16 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Height | 20 mm |
| Packaging | Reel |
| Voltage Rating | 63 V |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Diameter | 800 µm |
| Lead Pitch | 7.5 mm |
| REACH SVHC | Yes |
| Features | General Purpose |
| Impedance | 29 mΩ |
| Lifecycle Status | Production (Last Updated: 5 months ago) |
| Ripple Current @ Low Frequency | 1.625 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.15 A @ 100 kHz |
Stock: 108
Distributors
pcbx
pcbxUnit Price$1.33882
Ext.Price$1.33882
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.33882 | $1.33882 |
| 10 | $0.59930 | $5.99300 |
| 25 | $0.55509 | $13.87725 |
| 50 | $0.51414 | $25.70700 |
| 100 | $0.47620 | $47.62000 |
| 300 | $0.46539 | $139.61700 |
| 500 | $0.45483 | $227.41500 |
| 1000 | $0.44286 | $442.86000 |
