EK500A-02P
Manufacturer:
Dinkle
Mfr.Part #:
EK500A-02P
Datasheet:
Description:
Terminal Blocks Through Hole 4 5 mm 20 A 300 V 24 AWG to 12 AWG
| Parameter | Value |
|---|---|
| Termination | Screw |
| Max Operating Temperature | 120 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bulk |
| Voltage Rating | 300 V |
| RoHS | Compliant |
| Voltage | 300 V |
| Pitch | 5 mm |
| Current Rating | 20 A |
| Orientation | 45° (135°) Angle with Board |
| Color | Green |
| Number of Positions | 4 |
| Number of Positions Per Level | 2 |
| Number of Levels | 2 |
| Connection Method | Screw |
| Wire Gauge Range | 24 AWG to 12 AWG |
| Voltage Rating (IEC) | 320 V |
| Current Rating (IEC) | 24 A |
Stock: 755
Distributors
pcbx
pcbxUnit Price$0.51296
Ext.Price$0.51296
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.51296 | $0.51296 |
| 10 | $0.37731 | $3.77310 |
| 25 | $0.32887 | $8.22175 |
| 50 | $0.29620 | $14.81000 |
| 100 | $0.26798 | $26.79800 |
| 300 | $0.24206 | $72.61800 |
| 500 | $0.21865 | $109.32500 |
| 1000 | $0.20362 | $203.62000 |
| 3000 | $0.19123 | $573.69000 |
| 5000 | $0.17959 | $897.95000 |
