ELC09D470F
Manufacturer:
Panasonic
Mfr.Part #:
ELC09D470F
Datasheet:
Description:
Fixed Inductors Radial Through Hole 47 µH 10 % 1.2 A 110 mΩ
| Parameter | Value |
|---|---|
| Tolerance | 10 % |
| Termination | Radial |
| Diameter | 9.5 mm |
| Number of Pins | 2 |
| Resistance | 110 mΩ |
| Height | 8.9 mm |
| Packaging | Bulk |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Diameter | 600 µm |
| Lead Pitch | 5 mm |
| REACH SVHC | No SVHC |
| Contact Plating | Copper, Tin |
| Lead/Base Style | Radial |
| Self Resonant Frequency | 10 kHz |
| Current | 740 mA |
| Current Rating | 1.2 A |
| DC Resistance (DCR) | 110 mΩ |
| Test Frequency | 10 kHz |
| Military Standard | Not |
| Shielding | Unshielded |
| Inductance | 47 µH |
| Core Material | Ferrite |
| RMS Current (Irms) | 1.2 A |
| inductance tolerance | 10 % |
| Max DC Current | 1.2 A |
| Series Resistance | 110 mΩ |
| DC Current | 1.2 A |
| Schedule B | 8504500000 |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -20 °C |
| Height - Seated (Max) | 8.9 mm |
| Type | Wirewound |
