ELG337M400AT3AA
Manufacturer:
KEMET
Mfr.Part #:
ELG337M400AT3AA
Datasheet:
Description:
Aluminum Electrolytic Capacitors 35.00mmD×35.00mmH Through Hole 330 µF 20 % 400 V
| Parameter | Value |
|---|---|
| Capacitance | 330 µF |
| Voltage Rating (DC) | 400 V |
| Tolerance | 20 % |
| ESR (Equivalent Series Resistance) | 195 mΩ |
| Life (Hours) | 2000 Hours |
| Ripple Current | 1.35 A |
| Height - Seated (Max) | 37 mm |
| Length | 35 mm |
| Termination | Snap in |
| Diameter | 35 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -25 °C |
| Leakage Current | 2.64 mA |
| Dissipation Factor | 0.15 % |
| Height | 35 mm |
| Voltage Rating | 400 V |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Diameter | 800 µm |
| Lead Pitch | 10 mm |
| Voltage | 400 V |
| REACH SVHC | No SVHC |
| Dielectric Material | Aluminium |
| Lead Length | 5.8 mm |
| Packaging | Bulk |
| Ripple Current @ High Frequency | 1.9575 A @ 10 kHz |
| Ripple Current @ Low Frequency | 1.35 A @ 120 Hz |
Stock: 431
Distributors
pcbx
pcbxUnit Price$4.58031
Ext.Price$4.58031
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $4.58031 | $4.58031 |
| 10 | $3.24676 | $32.46760 |
| 25 | $2.95935 | $73.98375 |
| 50 | $2.69737 | $134.86850 |
| 100 | $2.48204 | $248.20400 |
