ESP-07
Manufacturer:
Ai-Thinker
Mfr.Part #:
ESP-07
Datasheet:
Description:
RF - Transceiver Modules and Modems Module SMD/SMT WiFi 802.11 b/g/n 2.4 GHz to 2.5 GHz
| Parameter | Value |
|---|---|
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Reel |
| Frequency | 2.4 GHz to 2.5 GHz |
| Interface | UART, HSPI, I²C, I²S, IR Remote Control, GPIO, PWM |
| Max Supply Voltage | 3.6 V |
| Min Supply Voltage | 3 V |
| Data Rate | 72.2 Mbps |
| Current - Receiving | 50 mA to 56 mA |
| Current - Transmitting | 120 mA to 170 mA |
| Output Power | 20.5 W |
| Supply Voltage | 3 V to 3.6 V |
| Sensitivity (dBm) | -98 dBm |
| Standard | WiFi |
| Protocol | 802.11 b/g/n |
Stock: 2921
Distributors
pcbx
pcbxUnit Price$3.19094
Ext.Price$3.19094
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $3.19094 | $3.19094 |
| 10 | $2.73792 | $27.37920 |
| 25 | $2.43641 | $60.91025 |
| 50 | $2.16811 | $108.40550 |
| 100 | $1.92933 | $192.93300 |
| 300 | $1.86211 | $558.63300 |
| 500 | $1.79722 | $898.61000 |
