FTR-K1AK024T
Manufacturer:
Fujitsu
Mfr.Part #:
FTR-K1AK024T
Datasheet:
Description:
Power Relays Through Hole 16.67 mA 1.44 kΩ 24 V General Purpose
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 250 V |
| Length | 29 mm |
| Width | 12.7 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 440 V |
| Number of Pins | 8 |
| Height | 15.7 mm |
| Packaging | Tray |
| Depth | 12.7 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Contact Material(Contact Finish) | Silver |
| Max Current Rating | 17 A |
| Max Voltage Rating (DC) | 250 V |
| Throw Configuration | SPST |
| Contact Resistance | 100 mΩ |
| Max Voltage Rating (AC) | 440 V |
| Coil Voltage (DC) | 24 V |
| Coil Current | 16.67 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 1.44 kΩ |
| Relay Type | General Purpose |
| Operate Time | 15 ms |
| Release Time | 5 ms |
| Contact Current Rating | 16 A |
| power consumption | 53 mW |
| Termination Style | PC Pin |
| Switching Voltage | 440 VAC, 300 VDC |
| Coil Power | 400 mW |
