FTS-102-01-L-D
Manufacturer:
Samtec
Mfr.Part #:
FTS-102-01-L-D
Datasheet:
Description:
Headers and Wire Housings Through Hole Header, Cuttable Number of Positions:4 Pitch:1.27 mm
| Parameter | Value |
|---|---|
| Length | 2.54 mm |
| Termination | Solder |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -55 °C |
| Height | 4.17 mm |
| Packaging | Bulk |
| Depth | 3.42 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Contact Plating | Gold |
| Pitch | 1.27 mm |
| Current Rating | 3.4 A |
| Max Current Rating | 1.75 A |
| Orientation | Straight |
| Color | Black |
| Gender | Pin (Male) |
| Number of Contacts | 4 |
| Connector Type | Header, Cuttable |
| Number of Positions | 4 |
| Number of Rows | 2 |
| Row Spacing | 1.27 mm |
| Housing Material | Polymer |
| Housing Color | Black |
| Contact Mating Length | 3.048 mm |
| Mating Post Length | 3.05 mm |
| Schedule B | 8536694040 |
| Termination Post Length | 2.29 mm |
Stock: 147
Distributors
pcbx
pcbxUnit Price$0.60700
Ext.Price$0.60700
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.60700 | $0.60700 |
| 10 | $0.57987 | $5.79870 |
| 25 | $0.55396 | $13.84900 |
| 50 | $0.52920 | $26.46000 |
| 100 | $0.44884 | $44.88400 |
| 300 | $0.40903 | $122.70900 |
| 500 | $0.37275 | $186.37500 |
| 1000 | $0.31889 | $318.89000 |
| 3000 | $0.25633 | $768.99000 |
| 5000 | $0.20604 | $1030.20000 |
| 10000 | $0.14363 | $1436.30000 |
