G6DS-1A-DC5
Manufacturer:
Omron
Mfr.Part #:
G6DS-1A-DC5
Datasheet:
Description:
Power Relays Through Hole 36 mA 139 Ω 5 V General Purpose
| Parameter | Value |
|---|---|
| Length | 20.3 mm |
| Width | 5.08 mm |
| Termination | PC Pin |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 4 |
| Height | 12.4 mm |
| Packaging | Bulk |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Weight | 2.3 g |
| Max Current Rating | 5 A |
| Max Voltage Rating (DC) | 30 V |
| Throw Configuration | SPST |
| Max Voltage Rating (AC) | 250 V |
| Coil Voltage (DC) | 5 V |
| Coil Current | 36 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 139 Ω |
| Relay Type | General Purpose |
| Operate Time | 10 ms |
| Release Time | 5 ms |
| Contact Current Rating | 5 A |
| power consumption | 180 mW |
| Termination Style | PC Pin |
| Switching Voltage | 250 VAC, 30 VDC |
| Coil Power | 180 mW |
| Must Operate Voltage | 3.5 V |
| Must Release Voltage | 250 mV |
