GSA1212D-15
Manufacturer:
GTL-POWER
Mfr.Part #:
GSA1212D-15
Datasheet:
Description:
DC to DC Converters Plugin Through Hole Nominal Input Voltage:12 V Min Input Voltage:9 V Max Input Voltage:18 V 83 %
| Parameter | Value |
|---|---|
| Length | 50.8 mm |
| Width | 25.4 mm |
| Max Operating Temperature | 80 °C |
| Min Operating Temperature | -25 °C |
| Height | 11.8 mm |
| Packaging | Box |
| RoHS | Compliant |
| Min Input Voltage | 9 V |
| Max Input Voltage | 18 V |
| Isolation Voltage | 1.5 kV |
| Output Power | 15 W |
| Efficiency | 83 % |
| Nominal Input Voltage | 12 V |
| Output Current-Channel 1 | 625 mA |
| Output Current-Channel 2 | 625 mA |
| Output Voltage-Channel 1 | 12 V |
| Output Voltage-Channel 2 | -12 V |
Stock: 7
Distributors
pcbx
pcbxUnit Price$11.10451
Ext.Price$11.10451
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $11.10451 | $11.10451 |
| 10 | $9.54749 | $95.47490 |
| 25 | $8.95763 | $223.94075 |
| 50 | $8.40421 | $420.21050 |
| 100 | $7.88503 | $788.50300 |
