IHLP3232DZER6R8M11
Manufacturer:
Vishay
Mfr.Part #:
IHLP3232DZER6R8M11
Datasheet:
Description:
Fixed Inductors 8.64mmL×8.18mmW×4.00mmH SMD/SMT 6.8 µH 20 % 7 A 33.4 mΩ
| Parameter | Value |
|---|---|
| Tolerance | 20 % |
| Height - Seated (Max) | 3.99 mm |
| Length | 8.636 mm |
| Width | 8.18 mm |
| Termination | SMD/SMT |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -55 °C |
| Number of Pins | 2 |
| Composition(Kit Type) | Wirewound |
| Height | 4 mm |
| Depth | 8.26 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Self Resonant Frequency | 13 MHz |
| Current Rating | 7 A |
| DC Resistance (DCR) | 33.4 mΩ |
| Test Frequency | 100 kHz |
| Military Standard | Not |
| Shielding | Shielded |
| Inductance | 6.8 µH |
| Core Material | Ferrite |
| RMS Current (Irms) | 7 A |
| inductance tolerance | 20 % |
| Max DC Current | 6.7 A |
| Series Resistance | 33.4 mΩ |
| Saturation Current | 6.7 A |
| Schedule B | 8504500000 |
| Packaging | Reel |
| Type | Wirewound |
Stock: 331
Distributors
pcbx
pcbxUnit Price$0.93571
Ext.Price$0.93571
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.93571 | $0.93571 |
| 10 | $0.77347 | $7.73470 |
| 25 | $0.71757 | $17.93925 |
| 50 | $0.66571 | $33.28550 |
| 100 | $0.61760 | $61.76000 |
| 300 | $0.56644 | $169.93200 |
| 500 | $0.51953 | $259.76500 |
| 1000 | $0.49325 | $493.25000 |
