IPS1-105-01-L-D
Manufacturer:
Samtec
Mfr.Part #:
IPS1-105-01-L-D
Datasheet:
Description:
Headers and Wire Housings Through Hole Receptacle Number of Positions:10 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 13.08 mm |
| Termination | Solder |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Bulk |
| Voltage Rating | 777 V |
| Depth | 4.95 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Number of Terminals | 10 |
| Current Rating | 9 A |
| Orientation | Straight |
| Gender | Socket (Female) |
| Number of Contacts | 10 |
| Connector Type | Receptacle |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Row Spacing | 2.54 mm |
| Housing Material | Polymer |
| Number of Ports | 1 |
| Max Voltage Rating (AC) | 550 V |
| Termination Post Length | 2.54 mm |
Stock: 1366
Distributors
pcbx
pcbxUnit Price$1.58333
Ext.Price$1.58333
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.58333 | $1.58333 |
| 10 | $1.52046 | $15.20460 |
| 25 | $1.46009 | $36.50225 |
| 50 | $1.40209 | $70.10450 |
| 100 | $1.27043 | $127.04300 |
| 300 | $1.18963 | $356.88900 |
| 500 | $1.11397 | $556.98500 |
| 1000 | $1.01993 | $1019.93000 |
| 3000 | $0.83416 | $2502.48000 |
| 5000 | $0.68223 | $3411.15000 |
| 10000 | $0.51980 | $5198.00000 |
