D051515S-2W
Manufacturer:
JETEKPS
Mfr.Part #:
D051515S-2W
Datasheet:
Description:
DC to DC Converters SIP-6 Through Hole Nominal Input Voltage:5 V Min Input Voltage:4.5 V Max Input Voltage:5.5 V 80 %
| Parameter | Value |
|---|---|
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 85 °C |
| RoHS | Compliant |
| Packaging | Tube |
| Output Power | 2 W |
| Isolation Voltage | 1.5 kV |
| Max Input Voltage | 5.5 V |
| Nominal Input Voltage | 5 V |
| Min Input Voltage | 4.5 V |
| Output Voltage-Channel 1 | 15 V |
| Output Current-Channel 2 | 67 mA |
| Output Current-Channel 1 | 67 mA |
| Output Voltage-Channel 2 | 15 V |
| Efficiency | 80 % |
| Length | 19.6 mm |
| Width | 7 mm |
| Height | 10 mm |
Stock: 28
Distributors
pcbx
pcbxUnit Price$2.42746
Ext.Price$2.42746
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $2.42746 | $2.42746 |
| 10 | $1.99632 | $19.96320 |
| 25 | $1.83772 | $45.94300 |
| 50 | $1.69172 | $84.58600 |
| 100 | $1.55734 | $155.73400 |
| 300 | $1.50410 | $451.23000 |
| 500 | $1.45267 | $726.33500 |
| 1000 | $1.40747 | $1407.47000 |
