G1205S-1W
Manufacturer:
JETEKPS
Mfr.Part #:
G1205S-1W
Datasheet:
Description:
DC to DC Converters SIP-5 Through Hole Nominal Input Voltage:12 V Min Input Voltage:10.8 V Max Input Voltage:13.2 V 72 %
| Parameter | Value |
|---|---|
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 85 °C |
| RoHS | Compliant |
| Packaging | Tube |
| Output Power | 1 W |
| Isolation Voltage | 6 kV |
| Max Input Voltage | 13.2 V |
| Nominal Input Voltage | 12 V |
| Min Input Voltage | 10.8 V |
| Output Voltage-Channel 1 | 5 V |
| Output Current-Channel 2 | -100 mA |
| Output Current-Channel 1 | 100 mA |
| Output Voltage-Channel 2 | -5 V |
| Efficiency | 72 % |
| Length | 19.6 mm |
| Width | 9.5 mm |
| Height | 12.5 mm |
Stock: 16
Distributors
pcbx
pcbxUnit Price$2.91379
Ext.Price$2.91379
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $2.91379 | $2.91379 |
| 10 | $2.36611 | $23.66110 |
| 25 | $2.19772 | $54.94300 |
| 50 | $2.04131 | $102.06550 |
| 100 | $1.89606 | $189.60600 |
| 300 | $1.83803 | $551.40900 |
| 500 | $1.78179 | $890.89500 |
| 1000 | $1.72922 | $1729.22000 |
