JS24-K
Manufacturer:
Fujitsu
Mfr.Part #:
JS24-K
Datasheet:
Description:
Power Relays Through Hole 10.21 mA 2.35 kΩ 24 V Standard
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 24 V |
| Length | 29 mm |
| Width | 10 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 250 V |
| Number of Pins | 5 |
| Height | 12.5 mm |
| Packaging | Tube |
| Depth | 10 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Weight | 8 g |
| Contact Material(Contact Finish) | Cadmium, Gold, Silver |
| Current Rating | 8 A |
| Max Current Rating | 10 A |
| Max Voltage Rating (DC) | 300 V |
| Number of Contacts | 1 |
| Throw Configuration | SPDT |
| Max Voltage Rating (AC) | 400 V |
| Coil Voltage (DC) | 24 V |
| Coil Current | 10.21 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 2.35 kΩ |
| Relay Type | Standard |
| Operate Time | 10 ms |
| Contact Current Rating | 10 A |
| switching current | 10 A |
| power consumption | 245 mW |
| Switching Voltage | 400 VAC, 300 VDC |
| Coil Power | 245 mW |
| Must Operate Voltage | 16.8 V |
| Must Release Voltage | 2.4 V |
