KF250-3.5-4P-1
Manufacturer:
Kefa
Mfr.Part #:
KF250-3.5-4P-1
Datasheet:
Description:
Terminal Blocks Through Hole 4 3.5 mm 5 A 300 V 22 AWG to 18 AWG
| Parameter | Value |
|---|---|
| Termination | Tin |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bag |
| Voltage Rating | 300 V |
| RoHS | Compliant |
| Pitch | 3.5 mm |
| Current Rating | 5 A |
| Orientation | Vertical with Board |
| Color | Gray |
| Wire/Cable Gauge | 22 AWG to 18 AWG |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Number of Positions Per Level | 4 |
| Number of Levels | 1 |
| Connection Method | Push-In |
| Wire Gauge Range | 22 AWG to 18 AWG |
| Current Rating (IEC) | 5 A |
| Voltage Rating (IEC) | 400 V |
Stock: 3896
Distributors
pcbx
pcbxUnit Price$0.21638
Ext.Price$0.21638
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.21638 | $0.21638 |
| 10 | $0.19191 | $1.91910 |
| 50 | $0.17021 | $8.51050 |
| 100 | $0.14164 | $14.16400 |
| 500 | $0.11786 | $58.93000 |
| 1000 | $0.11200 | $112.00000 |
| 3000 | $0.10643 | $319.29000 |
| 5000 | $0.10114 | $505.70000 |
