LF50ABDT-TR
Manufacturer:
STMicroelectronics
Mfr.Part #:
LF50ABDT-TR
Datasheet:
Description:
Voltage Regulators - Linear DPAK SMD/SMT Positive Fixed 5 V 500 mA
| Parameter | Value |
|---|---|
| Length | 6.6 mm |
| Width | 6.2 mm |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 3 |
| Height | 2.4 mm |
| Packaging | Reel |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Positive |
| REACH SVHC | No SVHC |
| Weight | 4.535924 g |
| Dropout Voltage | 400 mV |
| Min Input Voltage | 3 V |
| Output Current | 500 mA |
| Output Voltage | 5 V |
| Output Type | Fixed |
| Lifecycle Status | Production (Last Updated: 1 year ago) |
| Accuracy | 1 % |
| Max Output Current | 500 mA |
| Input Bias Current | 500 µA |
| Quiescent Current | 1 mA |
| Max Input Voltage | 16 V |
| Number of Outputs | 1 |
| Min Output Voltage | 5 V |
| Nominal Output Voltage | 5 V |
| Number of Regulators | 1 |
| Output Voltage Accuracy | 1 % |
| Schedule B | 8542390000 |
| Load Regulation | 25 mV |
| Line Regulation | 25 mV |
| Max Output Voltage | 5 V |
Stock: 447
Distributors
pcbx
pcbxUnit Price$0.61814
Ext.Price$0.61814
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.61814 | $0.61814 |
| 10 | $0.50304 | $5.03040 |
| 25 | $0.46347 | $11.58675 |
| 50 | $0.42702 | $21.35100 |
| 100 | $0.39343 | $39.34300 |
| 300 | $0.37623 | $112.86900 |
| 500 | $0.35977 | $179.88500 |
| 1000 | $0.34290 | $342.90000 |
