LGU2C182MELB
Manufacturer:
Nichicon
Mfr.Part #:
LGU2C182MELB
Datasheet:
Description:
Aluminum Electrolytic Capacitors 30.00mmD×45.00mmH Through Hole 1.8 mF 20 % 160 V
| Parameter | Value |
|---|---|
| Capacitance | 1.8 mF |
| Voltage Rating (DC) | 160 V |
| Tolerance | 20 % |
| Life (Hours) | 3000 Hours |
| Ripple Current | 3.32 A |
| Height - Seated (Max) | 45 mm |
| Length | 45 mm |
| Termination | Snap in |
| Diameter | 30 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Leakage Current | 1.6 mA |
| Height | 45 mm |
| Packaging | Bulk |
| Voltage Rating | 160 V |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Pitch | 10 mm |
| Ripple Current (AC) | 3.32 A |
| Lifecycle Status | Production (Last Updated: 10 months ago) |
| Ripple Current @ Low Frequency | 3.32 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.98 A @ 50 kHz |
Stock: 66
Distributors
pcbx
pcbxUnit Price$4.97483
Ext.Price$4.97483
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $4.97483 | $4.97483 |
| 10 | $2.90334 | $29.03340 |
| 25 | $2.88239 | $72.05975 |
| 50 | $2.86159 | $143.07950 |
| 100 | $2.84093 | $284.09300 |
| 300 | $2.57501 | $772.50300 |
| 500 | $2.33396 | $1166.98000 |
| 1000 | $2.23393 | $2233.93000 |
