LQH3NPN2R2MJRL
Manufacturer:
Murata
Mfr.Part #:
LQH3NPN2R2MJRL
Datasheet:
Description:
Fixed Inductors 1212(3030 Metric) SMD/SMT 2.2 µH 20 % 1.8 A 81.6 mΩ
| Parameter | Value |
|---|---|
| Tolerance | 20 % |
| Height - Seated (Max) | 1.2 mm |
| Length | 2.9972 mm |
| Width | 2.9972 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Case Code (Imperial) | 1212 |
| Case Code (Metric) | 3030 |
| Composition(Kit Type) | Wirewound |
| Height | 1.2 mm |
| Packaging | Reel |
| RoHS | Compliant |
| Self Resonant Frequency | 45 MHz |
| Type | Wirewound |
| Current Rating | 1.8 A |
| DC Resistance (DCR) | 81.6 mΩ |
| Test Frequency | 1 MHz |
| Lifecycle Status | Production (Last Updated: 1 month ago) |
| Shielding | Shielded |
| Ambient Temperature Range High | 105 °C |
| Inductance | 2.2 µH |
| Core Material | Ferrite |
| RMS Current (Irms) | 2.2 A |
| Series Resistance | 81.6 mΩ |
| Saturation Current | 1.8 A |
| Schedule B | 8504500000 |
| Manufacturer Lifecycle Status | IN PRODUCTION (Last Updated: 1 month ago) |
Stock: 2995
Distributors
pcbx
pcbxUnit Price$0.17526
Ext.Price$0.17526
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.17526 | $0.17526 |
| 10 | $0.14363 | $1.43630 |
| 50 | $0.13018 | $6.50900 |
| 100 | $0.11798 | $11.79800 |
| 500 | $0.10723 | $53.61500 |
| 1000 | $0.09746 | $97.46000 |
| 3000 | $0.09178 | $275.34000 |
| 5000 | $0.08643 | $432.15000 |
| 10000 | $0.08139 | $813.90000 |
