178.6764.0001
Manufacturer:
Littelfuse
Mfr.Part #:
178.6764.0001
Datasheet:
Description:
Fuse Holders PCB 16 A 125 V Illuminated
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 125 V |
| Length | 14.2 mm |
| Width | 14.2 mm |
| Termination | PC Pin |
| Voltage Rating (AC) | 125 V |
| Height | 15.6 mm |
| Material | Thermoplastic |
| Packaging | Bulk |
| Voltage Rating | 125 V |
| Depth | 6 mm |
| RoHS | Compliant |
| Lead Pitch | 12 mm |
| Voltage | 125 V |
| REACH SVHC | Unknown |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Copper Alloy |
| Type | Blade |
| Current Rating | 16 A |
| Flammability Rating | UL94V-0 |
| Number of Circuits | 1 |
| Orientation | Vertical |
| Color | Black |
| Body Material | Thermoplastic |
| Number of Poles | 1 |
| Housing Material | Thermoplastic |
| Illumination Type | Illuminated |
| Fuse Current | 30 A |
| Size | 0.433" L x 0.152" W (11 mm x 3.85 mm) |
| For Use With | Miniature (ATM) |
Stock: 708
Distributors
pcbx
pcbxUnit Price$1.76045
Ext.Price$1.76045
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.76045 | $1.76045 |
| 10 | $1.49472 | $14.94720 |
| 25 | $1.35348 | $33.83700 |
| 50 | $1.22559 | $61.27950 |
| 100 | $1.10978 | $110.97800 |
| 300 | $1.07048 | $321.14400 |
| 500 | $1.03257 | $516.28500 |
| 1000 | $0.99842 | $998.42000 |
