M20-9960646
Manufacturer:
Harwin
Mfr.Part #:
M20-9960646
Datasheet:
Description:
Headers and Wire Housings Through Hole Male Pin Number of Positions:6 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 15.24 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bulk |
| Voltage Rating | 750 V |
| Depth | 10.9 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Max Current Rating | 3 A |
| Orientation | Right Angle |
| Color | Black |
| Number of Contacts | 6 |
| Connector Type | Male Pin |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Contact Resistance | 30 mΩ |
| Housing Color | Black |
| Contact Mating Length | 6.096 mm |
| Gender | Pin (Male) |
| Mating Post Length | 6.1 mm |
| Termination Post Length | 3 mm |
Stock: 2313
Distributors
pcbx
pcbxUnit Price$0.18124
Ext.Price$0.18124
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.18124 | $0.18124 |
| 10 | $0.14705 | $1.47050 |
| 50 | $0.13314 | $6.65700 |
| 100 | $0.12054 | $12.05400 |
| 500 | $0.11091 | $55.45500 |
| 1000 | $0.10205 | $102.05000 |
| 3000 | $0.09390 | $281.70000 |
| 5000 | $0.08640 | $432.00000 |
| 10000 | $0.07951 | $795.10000 |
