M20-9970546
Manufacturer:
Harwin
Mfr.Part #:
M20-9970546
Datasheet:
Description:
Headers and Wire Housings Through Hole Male Pin Number of Positions:10 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 750 V |
| Length | 12.7 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 750 V |
| Packaging | Bulk |
| Depth | 5.08 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| Insulation Resistance | 10 GΩ |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass, Bronze |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Max Current Rating | 3 A |
| Orientation | Straight |
| Color | Black |
| Gender | Male |
| Number of Contacts | 10 |
| Connector Type | Male Pin |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Row Spacing | 2.54 mm |
| Housing Material | Nylon |
| Contact Resistance | 30 mΩ |
| Housing Color | Black |
| Contact Mating Length | 8.509 mm |
| Mating Post Length | 8.51 mm |
Stock: 1422
Distributors
pcbx
pcbxUnit Price$0.34424
Ext.Price$0.34424
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.34424 | $0.34424 |
| 10 | $0.29158 | $2.91580 |
| 25 | $0.27622 | $6.90550 |
| 50 | $0.26167 | $13.08350 |
| 100 | $0.24790 | $24.79000 |
| 300 | $0.23420 | $70.26000 |
| 500 | $0.22125 | $110.62500 |
| 1000 | $0.21068 | $210.68000 |
| 3000 | $0.19904 | $597.12000 |
| 5000 | $0.18805 | $940.25000 |
| 10000 | $0.17908 | $1790.80000 |
