MKP1837410161G
Manufacturer:
Vishay
Mfr.Part #:
MKP1837410161G
Datasheet:
Description:
Film Capacitors Through Hole 100 nF 1 % Polypropylene (PP) Voltage Rating (DC):160 V Voltage Rating (AC):100 V
| Parameter | Value |
|---|---|
| Capacitance | 100 nF |
| Voltage Rating (DC) | 160 V |
| Tolerance | 1 % |
| Height - Seated (Max) | 10.922 mm |
| Length | 8.9916 mm |
| Width | 7.493 mm |
| Termination | PC Pin |
| Max Operating Temperature | 100 °C |
| Min Operating Temperature | -55 °C |
| Dielectric | Polypropylene (PP) |
| Voltage Rating (AC) | 100 V |
| Number of Pins | 2 |
| Height | 11 mm |
| Packaging | Ammo Pack |
| Voltage Rating | 160 V |
| Depth | 9 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Diameter | 500 µm |
| Lead Pitch | 5 mm |
| Voltage | 100 V |
| REACH SVHC | Unknown |
| Dielectric Material | PP |
Stock: 563
Distributors
pcbx
pcbxUnit Price$1.43900
Ext.Price$1.43900
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.43900 | $1.43900 |
| 10 | $0.98112 | $9.81120 |
| 25 | $0.88581 | $22.14525 |
| 50 | $0.79976 | $39.98800 |
| 100 | $0.74376 | $74.37600 |
| 300 | $0.69475 | $208.42500 |
| 500 | $0.64896 | $324.48000 |
| 1000 | $0.61961 | $619.61000 |
| 3000 | $0.59425 | $1782.75000 |
| 5000 | $0.56993 | $2849.65000 |
