NA-12W-K
Manufacturer:
Fujitsu
Mfr.Part #:
NA-12W-K
Datasheet:
Description:
LCD, OLED, Graphic Displays Through Hole TFT
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 220 V |
| Length | 14.9 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 250 V |
| Number of Pins | 8 |
| Height | 9.7 mm |
| Packaging | Bulk |
| Depth | 7.4 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Contact Material(Contact Finish) | Gold, Silver |
| Current Rating | 500 mA |
| Insertion Loss (dB) | 0.7 dB |
| Number of Contacts | 2 |
| Throw Configuration | DPDT |
| Display Type | TFT |
| Coil Voltage (DC) | 12 V |
| Coil Current | 11.67 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 1.028 kΩ |
| Operate Time | 6 ms |
| Contact Current Rating | 2 A |
| switching current | 2 A |
| power consumption | 140 mW |
| Coil Power | 140 mW |
| Coil Voltage (AC) | 12 V |
| Termination Style | PC Pin |
| Relay Type | Miniature |
| Must Operate Voltage | 9 V |
| Must Release Voltage | 1.2 V |
| Contact Form | 2 Form C (DPDT-NO, NC) |
| Switching Voltage | 250 VAC, 220 VDC |
| Release Time | 4 ms |
