EKZE250ELL681MJ20S
Manufacturer:
NCC
Mfr.Part #:
EKZE250ELL681MJ20S
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial, Can Through Hole 680 µF 20 % 25 V
| Parameter | Value |
|---|---|
| Capacitance | 680 µF |
| Voltage Rating (DC) | 25 V |
| Tolerance | 20 % |
| Life (Hours) | 4000 Hours |
| Ripple Current | 1.82 A |
| Height - Seated (Max) | 19.99 mm |
| Length | 20 mm |
| Termination | Radial |
| Diameter | 10 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Number of Pins | 2 |
| Height | 20 mm |
| Packaging | Bulk |
| Voltage Rating | 25 V |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Lead Pitch | 5 mm |
| REACH SVHC | Unknown |
| Dielectric Material | Aluminium |
| Impedance | 23 mΩ |
| Ripple Current @ Low Frequency | 1.092 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.82 A @ 100 kHz |
Stock: 8368
Distributors
pcbx
pcbxUnit Price$0.48194
Ext.Price$0.48194
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.48194 | $0.48194 |
| 10 | $0.30467 | $3.04670 |
| 25 | $0.26420 | $6.60500 |
| 50 | $0.22911 | $11.45550 |
| 100 | $0.20509 | $20.50900 |
| 300 | $0.18323 | $54.96900 |
| 500 | $0.16370 | $81.85000 |
| 1000 | $0.15011 | $150.11000 |
| 3000 | $0.13764 | $412.92000 |
| 5000 | $0.12621 | $631.05000 |
