UPJ1J221MHD6
Manufacturer:
Nichicon
Mfr.Part #:
UPJ1J221MHD6
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial,16.00mm×15.00mm Through Hole 220 µF 20 % 63 V
| Parameter | Value |
|---|---|
| Capacitance | 220 µF |
| Voltage Rating (DC) | 63 V |
| Tolerance | 20 % |
| Life (Hours) | 5000 Hours |
| Ripple Current | 820 mA |
| Height - Seated (Max) | 16.51 mm |
| Length | 15 mm |
| Termination | Radial |
| Diameter | 16 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Leakage Current | 415.8 µA |
| Height | 15 mm |
| Packaging | Bulk |
| Voltage Rating | 63 V |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Pitch | 7.5 mm |
| Impedance | 100 mΩ |
| Ripple Current (AC) | 820 mA |
| Lifecycle Status | Production (Last Updated: 1 year ago) |
| Ripple Current @ Low Frequency | 820 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.12 A @ 10 kHz |
Stock: 400
Distributors
pcbx
pcbxUnit Price$0.96993
Ext.Price$0.96993
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.96993 | $0.96993 |
| 10 | $0.62750 | $6.27500 |
| 25 | $0.55146 | $13.78650 |
| 50 | $0.48463 | $24.23150 |
| 100 | $0.43946 | $43.94600 |
| 300 | $0.39873 | $119.61900 |
| 500 | $0.36177 | $180.88500 |
| 1000 | $0.33732 | $337.32000 |
| 3000 | $0.31562 | $946.86000 |
| 5000 | $0.29531 | $1476.55000 |
