UVR2W101MRD
Manufacturer:
Nichicon
Mfr.Part #:
UVR2W101MRD
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial, Can Through Hole 100 µF 20 % 450 V
| Parameter | Value |
|---|---|
| Capacitance | 100 µF |
| Voltage Rating (DC) | 450 V |
| Tolerance | 20 % |
| Life (Hours) | 2000 hours |
| Ripple Current | 350 mA |
| Height - Seated (Max) | 42.0116 mm |
| Length | 40 mm |
| Termination | Radial |
| Diameter | 22 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Number of Pins | 2 |
| Leakage Current | 1.9 mA |
| Dissipation Factor | 0.25 % |
| Height | 40 mm |
| Packaging | Bulk |
| Voltage Rating | 450 V |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Lead Diameter | 1 mm |
| Lead Pitch | 10 mm |
| REACH SVHC | No SVHC |
| Dielectric Material | Aluminium |
| Schedule B | 8532220040 |
| Ripple Current @ Low Frequency | 350 mA @ 120 Hz |
| Mount | Through Hole |
| Case/Package | Radial |
Stock: 83
Distributors
pcbx
pcbxUnit Price$3.09666
Ext.Price$3.09666
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $3.09666 | $3.09666 |
| 10 | $2.12779 | $21.27790 |
| 25 | $1.91703 | $47.92575 |
| 50 | $1.72715 | $86.35750 |
