OKY-T/10-D12P-C
Manufacturer:
Murata
Mfr.Part #:
OKY-T/10-D12P-C
Datasheet:
Description:
Board Mount Modules 33.00mmL×13.50mmW×8.40mmH SMD/SMT Current - Output 1:10 A Voltage - Output 1:5.5 V 94.5 %
| Parameter | Value |
|---|---|
| Length | 33 mm |
| Width | 13.462 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 7 |
| Power Rating | 50 W |
| Height | 8.382 mm |
| Packaging | Reel |
| Depth | 13.5 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Features | OCP, OTP, SCP, UVLO |
| Min Input Voltage | 8.3 V |
| Output Current | 10 A |
| Output Voltage | 5.5 V |
| Operating Supply Voltage | 12 V |
| Output Type | Adjustable |
| Lifecycle Status | EOL (Last Updated: 1 week ago) |
| Max Power Dissipation | 50 W |
| Power Dissipation | 55 W |
| Max Output Current | 10 A |
| Max Input Voltage | 14 V |
| Number of Outputs | 1 |
| Output Power | 50 W |
| Current - Output 1 | 10 A |
| Efficiency | 94.5 % |
| Voltage - Output 1 | 5.5 V |
| Min Output Voltage | 752.5 mV |
| Max Input Voltage (DC) | 14 V |
| Nominal Output Voltage | 5.5 V |
| Nominal Input Voltage | 12 V |
| Max Output Voltage | 5.5 V |
| Max Output Power | 50 W |
| Min Input Voltage (DC) | 8.3 V |
| Isolation | Non-Isolated |
