PG02S2403A
Manufacturer:
Delta
Mfr.Part #:
PG02S2403A
Datasheet:
Description:
Board Mount Modules 21.80mmL×9.10mmW×11.20mmH Through Hole Voltage - Output 1:3.3 V 72 %
| Parameter | Value |
|---|---|
| Length | 21.844 mm |
| Width | 9.144 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Height | 11.176 mm |
| Packaging | Tube |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Features | Remote On/Off, SCP, UVLO |
| Min Input Voltage | 18 V |
| Output Current | 500 mA |
| Output Voltage | 3.3 V |
| Max Power Dissipation | 2 W |
| Max Output Current | 500 mA |
| Max Input Voltage | 36 V |
| Number of Outputs | 1 |
| Isolation Voltage | 1 kV |
| Output Power | 2 W |
| Efficiency | 72 % |
| Voltage - Output 1 | 3.3 V |
| Max Input Voltage (DC) | 36 V |
| Min Input Voltage (DC) | 18 V |
Stock: 263
Distributors
pcbx
pcbxUnit Price$6.42736
Ext.Price$6.42736
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $6.42736 | $6.42736 |
| 10 | $6.08881 | $60.88810 |
| 25 | $5.93236 | $148.30900 |
| 50 | $5.85797 | $292.89850 |
| 100 | $4.77478 | $477.47800 |
| 300 | $4.61961 | $1385.88300 |
| 500 | $4.46948 | $2234.74000 |
| 1000 | $4.32423 | $4324.23000 |
