PT65712
Manufacturer:
Apem
Mfr.Part #:
PT65712
Datasheet:
Description:
DIP Switches Through Hole BCD Number of Positions:4 Current Rating:400 mA Rotary for Tool
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 24 V |
| Length | 10 mm |
| Termination | Solder |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -20 °C |
| Circuit Type | BCD |
| RoHS | Compliant |
| Insulation Resistance | 100 MΩ |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Terminal Pitch | 2.54 mm |
| Current Rating | 400 mA |
| Max Voltage Rating (DC) | 24 V |
| Orientation | Straight |
| Throw Configuration | SP4T |
| Number of Positions | 4 |
| Actuator Material | Polyoxymethylene |
| Mechanical Life | 10 kcycles |
| Actuator Type | Rotary for Tool |
| Washable | Yes |
| Packaging | Tube |
