EEV-FC1E470P
Manufacturer:
Panasonic
Mfr.Part #:
EEV-FC1E470P
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial, Can - SMD SMD/SMT 47 µF 20 % 25 V
| Parameter | Value |
|---|---|
| Capacitance | 47 µF |
| Voltage Rating (DC) | 25 V |
| Tolerance | 20 % |
| Life (Hours) | 1000 hours |
| Ripple Current | 230 mA |
| Height - Seated (Max) | 6.1976 mm |
| Length | 6.2 mm |
| Width | 8.3 mm |
| Termination | SMD/SMT |
| Diameter | 8 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 25 V |
| Height | 6.2 mm |
| Packaging | Reel |
| Voltage Rating | 25 V |
| Lead Free | Contains Lead |
| RoHS | Compliant |
| Lead Diameter | 650 µm |
| Lead Pitch | 2.2 mm |
| Voltage | 25 V |
| Impedance | 400 mΩ |
| Ripple Current (AC) | 150 mA |
| Lead Length | 3.4 mm |
| Ripple Current @ Low Frequency | 172.5 mA @ 120 Hz |
| Ripple Current @ High Frequency | 230 mA @ 100 kHz |
| Mount | Surface Mount |
| Case/Package | Radial |
Stock: 460
Distributors
pcbx
pcbxUnit Price$0.37526
Ext.Price$0.37526
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.37526 | $0.37526 |
| 10 | $0.22024 | $2.20240 |
| 50 | $0.15941 | $7.97050 |
| 100 | $0.14096 | $14.09600 |
| 500 | $0.11067 | $55.33500 |
