SMH-105-02-L-S
Manufacturer:
Samtec
Mfr.Part #:
SMH-105-02-L-S
Datasheet:
Description:
Headers and Wire Housings SMD/SMT Receptacle Number of Positions:5 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 13.21 mm |
| Termination | Solder |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Tube |
| Depth | 10.8 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Orientation | Horizontal |
| Gender | Socket (Female) |
| Number of Contacts | 4 |
| Connector Type | Receptacle |
| Number of Positions | 5 |
| Number of Rows | 1 |
| Housing Material | Polymer |
| Contact Resistance | 10 mΩ |
| Housing Color | Black |
Stock: 57
Distributors
pcbx
pcbxUnit Price$1.25760
Ext.Price$1.25760
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.25760 | $1.25760 |
| 10 | $1.05502 | $10.55020 |
| 25 | $0.88508 | $22.12700 |
| 50 | $0.74251 | $37.12550 |
| 100 | $0.62291 | $62.29100 |
| 300 | $0.52257 | $156.77100 |
| 500 | $0.43839 | $219.19500 |
| 1000 | $0.36777 | $367.77000 |
| 3000 | $0.30853 | $925.59000 |
| 5000 | $0.25883 | $1294.15000 |
| 10000 | $0.21715 | $2171.50000 |
