SMM-104-01-S-S
Manufacturer:
Samtec
Mfr.Part #:
SMM-104-01-S-S
Datasheet:
Description:
Headers and Wire Housings Through Hole Receptacle Number of Positions:4 Pitch:2 mm
| Parameter | Value |
|---|---|
| Length | 8 mm |
| Termination | Solder |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Tube |
| Depth | 2 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Contact Plating | Gold |
| Pitch | 2 mm |
| Max Current Rating | 3.9 A |
| Orientation | Straight |
| Gender | Socket (Female) |
| Number of Contacts | 4 |
| Connector Type | Receptacle |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Housing Material | Polymer |
| Contact Resistance | 10 mΩ |
| Max Voltage Rating (AC) | 350 V |
| Housing Color | Black |
| Termination Post Length | 3.05 mm |
Stock: 266
Distributors
pcbx
pcbxUnit Price$1.50211
Ext.Price$1.50211
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.50211 | $1.50211 |
| 10 | $1.40409 | $14.04090 |
| 25 | $1.31247 | $32.81175 |
| 50 | $1.22683 | $61.34150 |
| 100 | $1.04790 | $104.79000 |
| 300 | $0.89507 | $268.52100 |
| 500 | $0.76453 | $382.26500 |
| 1000 | $0.65303 | $653.03000 |
| 3000 | $0.55779 | $1673.37000 |
| 5000 | $0.47644 | $2382.20000 |
| 10000 | $0.40694 | $4069.40000 |
