SMP-07V-BC
Manufacturer:
JST
Mfr.Part #:
SMP-07V-BC
Datasheet:
Description:
Headers and Wire Housings Free Hanging Plug Number of Positions:7 Pitch:2.5 mm
| Parameter | Value |
|---|---|
| Length | 18.2 mm |
| Width | 20.5 mm |
| Termination | Crimp |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Height | 7.5 mm |
| Packaging | Bulk |
| Voltage Rating | 250 V |
| RoHS | Compliant |
| Contact Material(Contact Finish) | Tin |
| Pitch | 2.5 mm |
| Current Rating | 3 A |
| Orientation | Straight |
| Gender | Male |
| Number of Contacts | 7 |
| Connector Type | Plug |
| Number of Positions | 7 |
| Number of Rows | 1 |
| Housing Material | Nylon |
Stock: 22
Distributors
pcbx
pcbxUnit Price$0.09917
Ext.Price$0.09917
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.09917 | $0.09917 |
| 10 | $0.08873 | $0.88730 |
| 50 | $0.07939 | $3.96950 |
| 100 | $0.07053 | $7.05300 |
| 500 | $0.06266 | $31.33000 |
| 1000 | $0.05970 | $59.70000 |
| 3000 | $0.05688 | $170.64000 |
| 5000 | $0.05419 | $270.95000 |
