SP3312TUTG
Manufacturer:
Littelfuse
Mfr.Part #:
SP3312TUTG
Datasheet:
Description:
TVS Diodes UDFN-8 SMD/SMT Working Voltage:3.3 V Clamping Voltage:13 V Peak Pulse Power:250 W Polarity:Bidirectional
| Parameter | Value |
|---|---|
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 8 |
| Leakage Current | 50 nA |
| Composition(Kit Type) | Zener |
| Packaging | Reel |
| RoHS | Compliant |
| Polarity | Bidirectional |
| Working Voltage | 3.3 V |
| Peak Pulse Current | 10 A |
| Number of Channels | 4 |
| Reverse Standoff Voltage | 3.3 V |
| Clamping Voltage | 13 V |
| Peak Pulse Power | 250 W |
| Power Line Protection | No |
| Number of Bidirectional Channels | 2 |
| Schedule B | 8536300000 |
| Voltage ESD Contact | 30 kV |
| Voltage ESD Air Gap | 30 kV |
| Diode Capacitance | 1.3 pF |
Stock: 3222
Distributors
pcbx
pcbxUnit Price$0.45055
Ext.Price$0.45055
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.45055 | $0.45055 |
| 10 | $0.37446 | $3.74460 |
| 25 | $0.35109 | $8.77725 |
| 50 | $0.32918 | $16.45900 |
| 100 | $0.30863 | $30.86300 |
| 300 | $0.30171 | $90.51300 |
| 500 | $0.29495 | $147.47500 |
| 1000 | $0.29067 | $290.67000 |
| 3000 | $0.28127 | $843.81000 |
