SSW-117-01-T-S
Manufacturer:
Samtec
Mfr.Part #:
SSW-117-01-T-S
Datasheet:
Description:
Headers and Wire Housings Through Hole Receptacle, Socket Number of Positions:17 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 655 V |
| Length | 43.7 mm |
| Width | 2.41 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Voltage Rating (AC) | 465 V |
| Height | 8.51 mm |
| Packaging | Bulk |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Lead Length | 2.64 mm |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Max Current Rating | 6.9 A |
| Orientation | Straight |
| Color | Black |
| Gender | Receptacle |
| Number of Contacts | 17 |
| Connector Type | Receptacle, Socket |
| Number of Positions | 17 |
| Number of Rows | 1 |
| Housing Material | Plastic |
| Contact Resistance | 10 mΩ |
| Max Voltage Rating (AC) | 550 V |
| Housing Color | Black |
| Schedule B | 8536694040 |
Stock: 96
Distributors
pcbx
pcbxUnit Price$1.20801
Ext.Price$1.20801
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.20801 | $1.20801 |
| 10 | $1.17791 | $11.77910 |
| 25 | $1.14856 | $28.71400 |
| 50 | $1.11996 | $55.99800 |
| 100 | $0.95154 | $95.15400 |
| 300 | $0.89651 | $268.95300 |
| 500 | $0.84467 | $422.33500 |
| 1000 | $0.63180 | $631.80000 |
| 3000 | $0.51236 | $1537.08000 |
| 5000 | $0.41550 | $2077.50000 |
| 10000 | $0.36078 | $3607.80000 |
