STW48N60M2-4
Manufacturer:
STMicroelectronics
Mfr.Part #:
STW48N60M2-4
Datasheet:
Description:
MOSFETs TO-247-4 Through Hole N-Channel number of channels:1 300 W 600 V Continuous Drain Current (ID):42 A 70 nC
| Parameter | Value |
|---|---|
| Max Operating Temperature | 150 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Tube |
| RoHS | Compliant |
| Lifecycle Status | Production (Last Updated: 6 months ago) |
| Max Power Dissipation | 300 W |
| Power Dissipation | 300 W |
| Number of Channels | 1 |
| Input capacitance | 3.06 nF |
| Continuous Drain Current (ID) | 42 A |
| Rds On Max | 70 mΩ |
| Drain to Source Voltage (Vdss) | 600 V |
| FET Type(Transistor Polarity) | N-Channel |
| Gate Charge | 70 nC |
| Drain to Source Resistance | 60 mΩ |
| Gate to Source Voltage (Vgs) | -25 V, 25 V |
| Drain to Source Breakdown Voltage (Vds) | 600 V |
| Gate to Source Threshold Voltage | 2 V |
Stock: 62
Distributors
pcbx
pcbxUnit Price$5.29376
Ext.Price$5.29376
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $5.29376 | $5.29376 |
| 10 | $4.60980 | $46.09800 |
| 25 | $4.01421 | $100.35525 |
| 50 | $3.49557 | $174.77850 |
| 100 | $3.04394 | $304.39400 |
| 300 | $2.65066 | $795.19800 |
| 500 | $2.30818 | $1154.09000 |
