TSW-102-07-L-S
Manufacturer:
Samtec
Mfr.Part #:
TSW-102-07-L-S
Datasheet:
Description:
Headers and Wire Housings Through Hole Header Number of Positions:2 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 5.08 mm |
| Width | 2.54 mm |
| Termination | Solder |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Bulk |
| Voltage Rating | 550 V |
| Depth | 2.54 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| REACH SVHC | No SVHC |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Current Rating | 7.6 A |
| Max Current Rating | 7.6 A |
| Orientation | Straight |
| Color | Black |
| Gender | Pin (Male) |
| Number of Contacts | 2 |
| Connector Type | Header |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Housing Material | Polyester |
| Max Voltage Rating (AC) | 550 V |
| Housing Color | Black |
| Contact Mating Length | 5.842 mm |
| Mating Post Length | 5.84 mm |
| Termination Post Length | 2.54 mm |
Stock: 32509
Distributors
pcbx
pcbxUnit Price$0.08139
Ext.Price$0.08139
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.08139 | $0.08139 |
| 10 | $0.07841 | $0.78410 |
| 50 | $0.07554 | $3.77700 |
| 100 | $0.07277 | $7.27700 |
| 500 | $0.07010 | $35.05000 |
| 1000 | $0.05882 | $58.82000 |
| 3000 | $0.04928 | $147.84000 |
| 5000 | $0.04129 | $206.45000 |
| 10000 | $0.03634 | $363.40000 |
| 30000 | $0.03340 | $1002.00000 |
| 50000 | $0.03069 | $1534.50000 |
