TSW-102-15-T-S
Manufacturer:
Samtec
Mfr.Part #:
TSW-102-15-T-S
Datasheet:
Description:
Headers and Wire Housings Through Hole Header Number of Positions:2 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 5.08 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Bulk |
| Depth | 2.54 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Max Current Rating | 7.6 A |
| Orientation | Straight |
| Gender | Pin (Male) |
| Number of Contacts | 2 |
| Connector Type | Header |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Housing Material | Polyester |
| Max Voltage Rating (AC) | 550 V |
| Housing Color | Black |
| Mating Post Length | 13.5 mm |
| Termination Post Length | 2.79 mm |
Stock: 1817
Distributors
pcbx
pcbxUnit Price$0.11883
Ext.Price$0.11883
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.11883 | $0.11883 |
| 10 | $0.10328 | $1.03280 |
| 50 | $0.08977 | $4.48850 |
| 100 | $0.07259 | $7.25900 |
| 500 | $0.06198 | $30.99000 |
| 1000 | $0.04634 | $46.34000 |
| 3000 | $0.03729 | $111.87000 |
| 5000 | $0.03001 | $150.05000 |
