UCD1C102MNL1GS
Manufacturer:
Nichicon
Mfr.Part #:
UCD1C102MNL1GS
Datasheet:
Description:
Aluminum Electrolytic Capacitors 10.00mmD×13.50mmH SMD/SMT 1 mF 20 % 16 V
| Parameter | Value |
|---|---|
| Capacitance | 1 mF |
| Voltage Rating (DC) | 16 V |
| Tolerance | 20 % |
| Life (Hours) | 1000 Hours |
| Ripple Current | 950 mA |
| Height - Seated (Max) | 14 mm |
| Length | 13.5 mm |
| Termination | SMD/SMT |
| Diameter | 10 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Leakage Current | 3 µA |
| Dissipation Factor | 0.16 % |
| Height | 13.5 mm |
| Voltage Rating | 16 V |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Weight | 1.630013 g |
| Impedance | 80 mΩ |
| Ripple Current (AC) | 950 mA |
| Lifecycle Status | Production (Last Updated: 10 months ago) |
| Schedule B | 8532220020 |
| Lead Pitch | 4.5 mm |
| Packaging | Reel |
| Ripple Current @ High Frequency | 950 mA @ 100 kHz |
| Ripple Current @ Low Frequency | 475 mA @ 120 Hz |
Stock: 1505
Distributors
pcbx
pcbxUnit Price$0.85750
Ext.Price$0.85750
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.85750 | $0.85750 |
| 10 | $0.40438 | $4.04380 |
| 25 | $0.39713 | $9.92825 |
| 50 | $0.39001 | $19.50050 |
| 100 | $0.38301 | $38.30100 |
| 300 | $0.34145 | $102.43500 |
| 500 | $0.30440 | $152.20000 |
| 1000 | $0.27137 | $271.37000 |
| 3000 | $0.24194 | $725.82000 |
