VE-100M1ETR-0505
Manufacturer:
Lelon
Mfr.Part #:
VE-100M1ETR-0505
Datasheet:
Description:
Aluminum Electrolytic Capacitors SMD,5.00mm×5.30mm SMD/SMT 10 µF 20 % 25 V
| Parameter | Value |
|---|---|
| Capacitance | 10 µF |
| Voltage Rating (DC) | 25 V |
| Tolerance | 20 % |
| Life (Hours) | 2000 Hours |
| Ripple Current | 44 mA |
| Height - Seated (Max) | 5.5 mm |
| Length | 5.3 mm |
| Termination | SMD/SMT |
| Diameter | 5 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Leakage Current | 3 µA |
| Dissipation Factor | 0.14 % |
| Height | 5.3 mm |
| Packaging | Reel |
| Voltage Rating | 25 V |
| RoHS | Compliant |
| Lead Pitch | 1.5 mm |
| Ripple Current @ Low Frequency | 35 mA @ 120 Hz |
