VIPER37HE
Manufacturer:
STMicroelectronics
Mfr.Part #:
VIPER37HE
Datasheet:
Description:
Voltage Regulators - Switching SDIP-10 Through Hole Flyback 800 V
| Parameter | Value |
|---|---|
| Length | 10.16 mm |
| Max Operating Temperature | 150 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 10 |
| Power Rating | 25 W |
| Packaging | Tube |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Min Input Voltage | 85 V |
| Output Voltage | 800 V |
| Lifecycle Status | Production (Last Updated: 10 months ago) |
| Max Power Dissipation | 25 W |
| Max Supply Voltage | 23.5 V |
| Min Supply Voltage | 8.5 V |
| Breakdown Voltage | 800 V |
| Operating Supply Current | 3.5 mA |
| Max Supply Current | 3.5 mA |
| Topology | Flyback |
| Switching Frequency | 115 kHz |
| Max Input Voltage | 265 V |
| Number of Outputs | 1 |
| Output Power | 25 W |
| Max Duty Cycle | 80 % |
| Max Input Voltage (AC) | 265 V |
| Min Input Voltage (AC) | 85 V |
| Schedule B | 8542390000 |
Stock: 941
Distributors
pcbx
pcbxUnit Price$1.13877
Ext.Price$1.13877
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.13877 | $1.13877 |
| 10 | $0.84467 | $8.44670 |
| 25 | $0.64462 | $16.11550 |
| 50 | $0.63079 | $31.53950 |
| 100 | $0.61726 | $61.72600 |
| 300 | $0.59594 | $178.78200 |
| 500 | $0.57537 | $287.68500 |
| 1000 | $0.57451 | $574.51000 |
| 3000 | $0.56340 | $1690.20000 |
