XVB1LUR50D
Manufacturer:
SunLED
Mfr.Part #:
XVB1LUR50D
Datasheet:
Description:
LEDs 13.2mmL×6.00mmW×6.00mmH Through Hole Red 617 nm 30 mA 2.3 V
| Parameter | Value |
|---|---|
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bulk |
| Voltage Rating | 1.9 V |
| RoHS | Compliant |
| Current | 10 mA |
| Forward Current | 30 mA |
| Forward Voltage | 2.3 V |
| Lifecycle Status | Production (Last Updated: 1 year ago) |
| Color | Red |
| Illumination Color | Red |
| Lens Style | Diffused |
| Luminous Intensity | 39 mcd |
| Element Configuration | Single |
| Viewing Angle | 60 ° |
| Wavelength | 627 nm |
| Lens Transparency | Diffused |
| Lens Color | Red |
| Dominant Wavelength/CCT (K) | 617 nm |
Stock: 3148
Distributors
pcbx
pcbxUnit Price$0.31322
Ext.Price$0.31322
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.31322 | $0.31322 |
| 10 | $0.21646 | $2.16460 |
| 50 | $0.18331 | $9.16550 |
| 100 | $0.15523 | $15.52300 |
| 500 | $0.12770 | $63.85000 |
| 1000 | $0.11866 | $118.66000 |
| 3000 | $0.11030 | $330.90000 |
| 5000 | $0.10253 | $512.65000 |
| 10000 | $0.09727 | $972.70000 |
