DA-06-B-T
Manufacturer:
ksswitch
Mfr.Part #:
DA-06-B-T
Datasheet:
Description:
DIP Switches Through Hole SPST Number of Positions:6 Current Rating:25 mA Slide
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 24 V |
| Termination | PC Pin |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -30 °C |
| Voltage Rating (AC) | 500 V |
| Circuit Type | SPST |
| Packaging | Tube |
| RoHS | Compliant |
| Contact Material(Contact Finish) | Gold |
| Terminal Pitch | 2.54 mm |
| Current Rating | 25 mA |
| Number of Positions | 6 |
| Actuator Type | Slide |
Stock: 18
Distributors
pcbx
pcbxUnit Price$0.53059
Ext.Price$0.53059
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.53059 | $0.53059 |
| 10 | $0.43152 | $4.31520 |
| 25 | $0.39519 | $9.87975 |
| 50 | $0.36192 | $18.09600 |
| 100 | $0.33145 | $33.14500 |
| 300 | $0.30355 | $91.06500 |
| 500 | $0.27800 | $139.00000 |
