3250W-1-202
Manufacturer:
Bourns
Mfr.Part #:
3250W-1-202
Datasheet:
Description:
Variable Resistors and Potentiometers Through Hole 2 kΩ 5 % Number of Turns:25 1 W
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 500 V |
| Tolerance | 5 % |
| Length | 12.7 mm |
| Width | 12.7 mm |
| Termination | Pin |
| Max Operating Temperature | 150 °C |
| Min Operating Temperature | -65 °C |
| Resistance | 2 kΩ |
| Power Rating | 1 W |
| Composition(Kit Type) | Wirewound |
| Temperature Coefficient | 50 ppm/°C |
| Number of Turns | 25 |
| Taper | Linear |
| Height | 12.7 mm |
| Packaging | Reel |
| Depth | 5.59 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| REACH SVHC | No SVHC |
| Weight | 1.700971 g |
| Military Standard | Not |
| Max Power Dissipation | 1 W |
| Color | Blue |
| Schedule B | 8533310000 |
| RoHS | Compliant |
Stock: 18
Distributors
pcbx
pcbxUnit Price$21.86568
Ext.Price$21.86568
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $21.86568 | $21.86568 |
| 10 | $17.93557 | $179.35570 |
| 25 | $16.27700 | $406.92500 |
| 50 | $15.21946 | $760.97300 |
| 100 | $14.27476 | $1427.47600 |
| 300 | $13.90056 | $4170.16800 |
| 500 | $13.53610 | $6768.05000 |
| 1000 | $13.52413 | $13524.13000 |
