PT19-21B/L41/TR8
Manufacturer:
Everlight
Mfr.Part #:
PT19-21B/L41/TR8
Datasheet:
Description:
Phototransistor 0603(1608 Metric) SMD/SMT 940 nm
| Parameter | Value |
|---|---|
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Number of Pins | 2 |
| Packaging | Reel |
| RoHS | Compliant |
| Number of Elements | 1 |
| Orientation | Top View |
| Lens Style | Flat |
| Power Dissipation | 75 mW |
| Max Collector Current | 20 mA |
| Collector Emitter Breakdown Voltage | 30 V |
| Fall Time | 15 µs |
| Rise Time | 15 µs |
| Wavelength | 940 nm |
| Lens Color | Black |
| Collector Emitter Voltage (VCEO) | 5 V |
| Dark Current | 100 nA |
| Max Breakdown Voltage | 30 V |
| Schedule B | 8541409500 |
Stock: 4400
Distributors
pcbx
pcbxUnit Price$0.07238
Ext.Price$0.07238
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.07238 | $0.07238 |
| 10 | $0.03619 | $0.36190 |
| 50 | $0.03223 | $1.61150 |
| 100 | $0.02871 | $2.87100 |
| 500 | $0.02509 | $12.54500 |
| 1000 | $0.02192 | $21.92000 |
| 3000 | $0.01961 | $58.83000 |
| 5000 | $0.01754 | $87.70000 |
