M64Y103KB40
Manufacturer:
Vishay
Mfr.Part #:
M64Y103KB40
Datasheet:
Description:
Variable Resistors and Potentiometers Through Hole 10 kΩ 10 % Number of Turns:21 500 mW
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 300 V |
| Tolerance | 10 % |
| Length | 9.7 mm |
| Width | 5 mm |
| Termination | Pin |
| Max Operating Temperature | 155 °C |
| Min Operating Temperature | -55 °C |
| Voltage Rating (AC) | 300 V |
| Resistance | 10 kΩ |
| Power Rating | 500 mW |
| Composition(Kit Type) | Cermet |
| Temperature Coefficient | 100 ppm/°C |
| Number of Turns | 21 |
| Taper | Linear |
| Height | 9.8044 mm |
| Packaging | Bulk |
| Depth | 5 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Weight | 820.009956 mg |
| Military Standard | Not |
| Max Power Dissipation | 500 mW |
Stock: 195
Distributors
pcbx
pcbxUnit Price$1.95877
Ext.Price$1.95877
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.95877 | $1.95877 |
| 10 | $1.64933 | $16.49330 |
| 25 | $1.53896 | $38.47400 |
| 50 | $1.45999 | $72.99950 |
| 100 | $1.37823 | $137.82300 |
| 300 | $1.30105 | $390.31500 |
| 500 | $1.22819 | $614.09500 |
| 1000 | $1.15941 | $1159.41000 |
| 3000 | $1.08920 | $3267.60000 |
| 5000 | $1.02325 | $5116.25000 |
