SM353LT
Manufacturer:
Honeywell
Mfr.Part #:
SM353LT
Datasheet:
Description:
Magnetic Sensors SOT-23 SMD/SMT Integrated Circuit (IC) ±2 mT Trip, ±0.3 mT Release
| Parameter | Value |
|---|---|
| Schedule B | 8542390000 |
| Max Supply Voltage | 5.5 V |
| Nominal Supply Current | 100 µA |
| Output Current | 310 nA |
| Length | 2.9 mm |
| Packaging | Reel |
| Type | Integrated Circuit (IC) |
| Mount | SMD/SMT |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 85 °C |
| Number of Pins | 3 |
| Width | 1.6 mm |
| Case/Package | SOT-23 |
| Output Type | Analog Voltage |
| REACH SVHC | Unknown |
| Min Supply Voltage | 1.65 V |
| Operating Supply Voltage | 5.5 V |
| Output Voltage | 150 mV |
| Height | 1.2 mm |
| Sensing Range | ±2 mT Trip, ±0.3 mT Release |
| Test Condition | -40 °C to 85 °C |
| Max Output Current | 100 µA |
| Max Supply Current | 800 µA |
| RoHS | Compliant |
